Programmable thermostat ST16

The ST16 is an electronic thermostat with almost the same characteristics as the E91 / TT16. The main difference is that its LCD screen is not touch-sensitive, so it uses 4 buttons to control the operation and programming of the thermostat. It is usually installed flush-mounted in a standard installation box Φ 60mm and depth 60mm, and supports ON / OFF temperature control, via a 16 A switching power relay output.

The thermostat has two NTC temperature sensors: a space sensor, built inside the thermostat itself, and a floor-mounted sensor (3 m long).

In addition to manually setting the desired temperature, the electronic thermostat ST16 has a real-time clock and has the ability to program the heating operation by both time and temperature. For working days, it is possible to program the heating in six different terms and set a different desired temperature for each of them. Over the weekend, it is possible to set two different dates and set a different desired temperature for each of them.

The ST16 also has a number of advanced settings that each user can use according to their own wishes and needs, and are described in the instructions that, like the measuring sensors, come with the thermostat.
