WiFi thermostat ET-61W

The ET-61W is a smart electronic thermostat used to control electric underfloor heating. It is a WiFi thermostat for wireless communication with your Internet network, which allows you (after installing the application “Warmme” on your smartphone), remote control of underfloor heating from any position where your mobile phone has Internet access.

The ET-61W has an LCD display for all important heating data, and 5 buttons located below it are used to program and control the operation of the thermostat. It is usually installed flush-mounted in a standard installation box Φ 60mm and depth 60mm, and supports ON / OFF temperature control, via a relay output of switching power 15 A. The thermostat has two NTC temperature sensors: a space sensor, built inside the thermostat, and a sensor floor (length 3 m).

In addition to manually setting the desired temperature, the electronic thermostat ET-61W has a real-time clock and has the ability to program the heating operation by both time and temperature. Each day of the week consists of 4 time periods (WAKE – waking up, LEAVE – leaving, RETURN – returning, SLEEP – sleeping) and each of them can be assigned the desired temperature.

The ET-61W also has a number of advanced settings that each user can use according to their own wishes and needs, and are described in the instructions that, like the measuring sensors, come with the thermostat.
